Solar panel PV Maxx 160W-P 18.6V

Brand: Maxx
Product Code: P0077
Availability: 6-10 business days
Planuojama gavimo data po užsakymo: 2025-05-16
90.10€
Ex Tax: 74.46€

Qty

This product has a minimum quantity of 3

The 160 W Maxx Solar Panel is a high-reliability product designed for long-term outdoor use in any environment. The 160 W Maxx module is an excellent choice for working in low light conditions. The panel is resistant to weather conditions. The 160 W Maxx module is designed to power batteries with a capacity of 100-120 Ah. When purchasing a solar battery, you will receive an MC4 serial connector for free.

Specification:

  • 160W Maxx model
  • Polycrystalline cells
  • Peak power: 160 W
  • Power tolerance: +3%
  • Max. power voltage Vmp: 18.6 V
  • Max. current Imp: 8.6 A
  • Open circuit voltage Voc: 22.32 V
  • Short-circuit current Isc: 9.6 A
  • Reverse current limitation: 15 A
  • Working temperature range: -40 °C to 85 °C
  • Length: 1480 mm
  • Width: 670 mm
  • Depth: 35 mm
  • Weight: 10.9 kg
  • Max. Static rear load, eg wind: 2400 Pa
  • Max. Static front load, eg snow: 5400 Pa
  • Hail resistance up to: 25 mm / 23 m/s
  • Frame: Anodized aluminum
  • Glass: Highly transparent tempered glass, thickness 3.2 mm
