Shelly Qubino Wave Pro 1 Professional 1-channel DIN rail smart switch with power metering.

Brand: Shelly
Product Code: Shelly Qubino Wave PRO1PM
Availability: 4-7 business days
Planuojama gavimo data po užsakymo: 2025-05-08
67.90€
Ex Tax: 56.12€

Qty

Wave Pro 1PM is a one-phase, 1-channel relay supporting up to 16 A. Equipped with an integrated power meter, Wave Pro 1PM allows you to measure the power consumption of all automated lights or heavier appliances. Different types of actions, scenarios, and schedules can be set to sync your environment to your daily activities or business needs. ​

  • ​1 output, 16 A​
  • Power metering​
  • DIN-rail mountable​
  • Extremely low power consumption: < 0.3 W​
  • Z-Wave frequency band: 868.4 MHz (CEPT countries)​
  • Latest technology: Z-Wave 800 Series​
  • Automatic set-up with SmartStart ​
  • Security 2 Authenticated for the highest level of security​
  • Over-the-air firmware updates​
  • Works with Z-Wave-certified gateways and over 4,000 Z-Wave devices​
Specifications :

  • Power supply: 110-240 V AC, 50/60 Hz
  • Power consumption: < 0.3W
  • Power measurement (W): Yes
  • Max. switching voltage AC: 240 V
  • Max. switching current AC: 16 A
  • Max. switching voltage DC: N/A
  • Max. switching current DC: N/A
  • Overheating protection: Yes
  • Overload protection: Yes
  • Overvoltage protection: Yes
  • Distance: Up to 40 m indoors (131 ft.) (depends on local condition)
  • Z-Wave repeater: Yes
  • CPU: Z-Wave S800
  • Z-Wave frequency bands: 868,4 MHz
  • Maximum radio frequency power transmitted in frequency bend(s): < 25 mW
  • Size (H x W x D): 94x19x69 ±0.5 mm / 3.70x0.75x2.71 ±0.02 in
  • Weight: 61 g / 2.15 oz.
  • Mounting: DIN rail
  • Screw terminals max. Torque: 0.4 Nm / 3.54 lbin
  • Conductor cross section: 0.5 to 2.5 mm² / 20 to 14 AWG (green connector) 0.5 to 1.5 mm² / 20 to 16 AWG (white connectors)
  • Conductor stripped length: 6 to 7 mm / 0.24 to 0.28 in (green connector) 5 to 6 mm / 0.20 to 0.24 in (white connectors)
  • Shell material: Plastic
  • Color: Red
  • Ambient temperature: -20°C to 40°C / -5°F to 105°F
  • Humidity: 30 % to 70 % RH
  • Max. Altitude: 2000 m / 6562 ft.
