Shelly Pro Dimmer 0/1-10V PM Lighting Controller

Brand: Shelly
Product Code: ProDim0/1-10VPM
Availability: 4-6 business days
Planuojama gavimo data po užsakymo: 2025-02-14
74.30€
Ex Tax: 61.41€

Qty

Shelly Pro Dimmer 0/1-10V PM lighting controller

The Shelly Pro Dimmer Lighting Controller supports both 0-10V and 1-10V controllers, so you can smoothly adjust the brightness of your lights to create the perfect ambience - from moody evening lighting to bright light conducive to work. The device offers full control over energy consumption, helping you lower your electricity bill and minimize your carbon footprint. You can easily integrate it into your existing lighting installations and use it with your favorite switches. Using it does not require a hub.

Integration with switches

Shelly Pro Dimmer works with single- and double-key switches, offering full flexibility to adapt to your preferences. With the ability to connect the Shelly Plus Add-On, the controller extends its functions to monitor environmental parameters such as humidity, temperature and light intensity. With this solution in place, you can fine-tune the conditions in your home to suit your needs, regardless of the style of switches you use.

Energy monitoring

The Shelly Pro Dimmer 0/1-10V PM precisely tracks voltage, current and power in real time. The collected data is available in the Shelly Smart Control app. The controller not only monitors energy consumption, but also helps optimize its use, leading to reduced bills. Current, voltage and power overload protections increase the safety of your electrical system.

Smart schedules and night mode

With Shelly Pro Dimmer, you can easily program lighting schedules that adapt to your lifestyle. Night mode automatically lowers the brightness level to create a cozy atmosphere, perfect for evening relaxation. Whether you're planning a movie night or want to gently dim the lights before bed, the controller will adapt to your needs.

Support for multiple protocols and platforms

Don't worry about potential compatibility issues. The Shelly Pro Dimmer lighting controller supports advanced communication protocols such as KNXnet/IP, MQTT and REST/Webhooks, allowing full integration with smart home platforms. It works with Home Assistant, Google Home, Amazon Alexa and more, offering easy lighting management with simple voice commands. The Wi-Fi Range Extender and Bluetooth Gateway feature allows for even greater range and connectivity flexibility.

Future-proof solution

The use of Shelly's advanced ESP32 C3 processor and 8 MB of flash memory makes the Shelly Pro Dimmer controller ready for future upgrades and new features, such as integration with the Matter standard. Thanks to this technology, the device runs smoothly and quickly, ensuring long-term stability and support for the latest smart home innovations.

ManufacturerShelly
Manufacturer codeProDim0/1-10VPM
Dimensions38.5 x 43.5 x 17 mm
Weight28.5 g
Maximum tightening torque0.4 Nm
Cable cross section0.2 to 2.5 mm²
Wire stripping length5-6 mm
Housing materialPlastic
Mounting locationIn wall console/behind wall/ceiling structure
Operating temperatureFrom -20°C to 40°C
Humidity30% to 70% RH
Maximum operating altitude2000 m
Power supply110-240 V~ 50/60 Hz
Power consumption< 1.5 W
External protection16A, trip characteristic B or C, short-circuit current 6 kA, energy limit class 3
Maximum switching voltage240 V~
Maximum switching current13 A
Maximum control current35 mA
Voltmeter voltage range110 - 240 V
Ampere range50 mA - 16 A
Accuracy of the meters±10%
Power and energy metersActive and apparent power / Active and apparent energy
Measurement data storageNone
Built-in temperature sensorYes
Wi-Fi protocol802.11 b/g/n
RF bandwidth2401-2495 MHz
Maximum RF power< 20 dBm
Wi-Fi rangeUp to 30 m indoors and up to 50 m outdoors (depending on local conditions)
Bluetooth protocol4.2
RF band2400-2483.5 MHz
Maximum RF power< 4 dBm
Bluetooth rangeUp to 30 m outdoors, up to 10 m indoors (depending on local conditions)
CPUShelly ESP32 C3
Clock frequency40 MHz
Flash memory8 MB
Number of schedules20
Webhooks (URL shares)20 with 5 URLs per webhook
ScriptsYes
MQTTYes
Advanced schedulingYes
KVS (Key-Value Store)Yes
Compatibility and CommunicationProtocols: KNXnet/IP, MQTT, REST/Webhooks, URC, Homey, Hubitat, Control4, Crestron, openHAB / Platforms: Alexa, Google Home, Android, iOS / App Compatibility: Home Assistant, Smart Things, Homey
