Rotary switch HD11-100 LW30-25A

Product Code: AS1788
Availability: Temporarily Out Of Stock
16.10€
Ex Tax: 13.31€

HD11 series rotary switch, designed and manufactured using advanced technology, suitable for controlling the main circuit, auxiliary circuit, three-phase and other loads. HD11 switches belong to a manual isolating switch according to IEC947-3 / DIN VDE 0660 (EN60947-3).

Specification:

  • Maximum voltage: 690V
  • Housing size: 64 * 64 mm
  • Standard: IEC60947-3
  • Maximum current: 25A
  • Number of poles: 3
  • Weight: 500g
