Radio transmitter Feather 32u4 RFM95 LoRa Radio, 868MHz, Adafruit 3078

Brand: Adafruit
Product Code: AN-13280
Availability: 4-6 business days
Planned delivery date after ordering: 2025-05-06
59.70€
Ex Tax: 49.34€

Qty

Radio transmitter/receiver operating in the LoRa standard powered with the rechargeable Li-Pol battery or via USB, it is running at frequencies of 868/915 MHz. The heart of the module is an 8-bit ATmega32u4 microcontroller with a clock frequency of 8 MHz, it has 32 kb of Flash memory and 2 KB of RAM. It is ideal for IoT projects (Internet of Things) or those that require mobility due to the possibility of powering with the Li-Pol rechargeable battery. In case of detection of USB power, the module automatically switches the power source and begins to charge the battery.

Specification:

  • Adafruit Feather 32u4:
    • Processor: ATmega32u4 8MHz
    • Interface: USB, serial, I2C, SPI
    • GPIO pins: 20
    • PWM pins: 7
    • Analog inputs: 10
    • Supported rechargeable batteries: Li-Pol, 3.7 V
    • The rechargeable battery charging current: 100mA
    • Dimensions: 51 x 23 x 8 mm
    • Weight: 5.5 g
  • Radio module:
    • Signal power: up to 100 MW (from 5 dBm to 20 dBm)
    • Current consumption:
      • Sleep mode: 300 µA
      • Broadcasting at full power: up to 120 mA
      • Listening mode: 40 mA
    • The ability to attach the antenna or u.FL connectors

Useful links:
Manufacturer website
Manual
