LCD IPS Display 2'' 320x240px, SPI, 65K RGB, for Raspberry Pi Pico, Waveshare 19888

Brand: Waveshare
Product Code: AN-19715
Availability: Temporarily Out Of Stock
18.00€
Ex Tax: 14.88€
IPS display designed to work with Raspberry Pi Pico board. The module is based on an ST7789VW chip and communicates via an SPI interface. The screen diagonal is 2.00" and its resolution is 320x240px. It is capable of displaying 65,000 colors that are part of the RGB gamut. The size of a single-pixel is 0.1275 x 0.1275 mm. The module has been equipped with four buttons for any use by the user.

Specification:
  • Operating voltage: from 2.6 V to 5.5 V
  • Interface: SPI 4-wire
  • Display type: IPS
  • Chip: ST7789VW
  • Diagonal: 2,00"
  • Resolution: 320x240px
  • Number of displayed colors: 65k RGB
  • Display size: 40.80 x 30.60 mm
  • Pixel size: 0.1275 x 0.1275 mm
  • Module size: 52 x 35 mm
