FANAR 371-B M5 6HX PM GAL TC tap
Ex Tax: 17.19€
Type of material | Type of coating | ||
|---|---|---|---|
| HSS | Medium performance high speed steel. is intended for the production of cutters with smaller diameters and machining of materials with a strength of up to 900 MPa | TiN | Standard. universal hard layer. |Compared to uncoated tools, it increases their service life to 300-400%. Recommended use when using cooling during processing |
| HSSE | Forged high-speed steel with very high performance and good durability. is used especially in tools with larger diameters and cutters with front blades | TICN | It ensures high hardness and at the same time good durability. Its advantage is a low coefficient of friction. It is used for milling high-strength steel. It has less temperature stability - cooling is necessary (e.g. when using emulsion) |
| HSS Co5 | High-speed steel with very high efficiency and good strength intended for milling cutters and processing of materials with a strength of up to 1200Mpa | TiAlN | Its advantage is high hardness at high temperatures. good oxidation resistance and low temperature conductivity. Universal use with emphasis on high speed milling without cooling. Suitable for milling hard materials. |
| HSS Co8 | High-speed steel with very high performance and good durability. ductility and temperature resistance. Designed for milling high-strength materials. asthenitic steels. hot work steel etc. | AlTiN | It has similar characteristics to the TiAlN coating. however, it shows greater hardness. High temperature stability. Designed for the most demanding applications. It provides an excellent result, especially in combination with the constant HSSE-PM (ASP 2030). Milling cutters made of this steel are coated with AlTiN as standard. |
| HSSE PM | High-quality powder-based high-speed steel with a homogeneous structure allowing the production of larger-sized tools and extended tool life. It is recommended for processing high-strength materials. hard materials. heavy-duty materials and titanium and its alloys. Milling cutters made of this material are supplied with an AlTiN coating as standard. | ||
| Types of Machine Tap Grooves | Cut | Application | |||
|---|---|---|---|---|---|
| Hole | Chip | ||||
| Easy | AD | Pass-through | Short. mediocre | ||
| CE | Blind | ||||
| Straight with a sloping rake face | B | Pass-through | Mediocre. long | ||
| Right screw | CE | Blind | Mediocre. long | ||
| R15 | 10°≤ Y 2 ≤20° | ||||
| R25 | 20°≤ Y 2 ≤30° | ||||
| R40 | 30°≤ Y 2 ≤40° | ||||
| R45 | 40°≤ Y 2 ≤50° | ||||
| Screw. left | D | Through-hole - with right thread | Medium long | ||
| L15 | 10°≤ Y 2 ≤20° | ||||
| L40 | 30°≤ Y 2 ≤40° | C | Through-hole - on the left thread | ||
The FANAR 371-B M5 6HX PM GAL TC tap is used to produce a metric M 5 thread. The FANAR 371-B M5 6HX PM GAL TC tap with a cut E/1.5-2P is used for tapping blind holes with a very short thread run. To be able to make an M 5 thread, you must first drill a hole with a diameter of 4.2*mm in the workpiece. Its total length is 70mm. The length of the working part is 14mm. The FANAR 371-B M5 6HX PM GAL TC tap is used to produce threads in materials such as: aluminum alloys 1% < Si < 7%. aluminum alloys Si >= 7%.
d%2%: 6
l%1% [mm]: 70
Execution: B
d [mm]: 4.2*
M [mm]: M5
l%2%: 14
a: 4.9
l3: 25
P [mm]: 0.8
Tolerance: -
Material type: PM/HSSE
Application: 1400
Coating: -
Cut: E/1.5-2P
DIN: DIN 371/376
l%2% R15: -
