Epever PWM Charging regulator LS3024B 30A

The new series of LandStar controllers is a new generation programmable Epsolar solar charge controller. All models are equipped with an aluminum heat sink for reliability in a high-temperature environment. RS-485 connects to the MT50 LCD Display (sold separately) or PC for real-time monitoring, custom settings and control, etc.

Main features:

• Three system voltage configurations: 12 V, 24 V or 12 V / 24 V automatic operation
• Highly efficient PWM power supply with temperature compensation
• 3 LEDs show PV charging, battery and load status
• Outdoor temperature sensor interface
• RS-485 bus communication
• Software update function
• Greater control possibilities with MT50 (sold separately) or PC
• Diversified load control modes: manual, light on / off, light on + timer, time control
• Battery type selection: gel, acid, AGM and user
• Real-time monitoring
• Programmable parameters
• LVD or SOC load disconnection function
• Energy statistics function


Specification:

• Nominal system voltage: 12 / 24 V DC Auto
• Battery types: Sealed, Gel, Liquid and Custom
• Nominal charging current: 30 A
• Nominal current of the receivers: 30 A
• The operating voltage range of the regulator is 8 ～ 32 V
• PV open circuit voltage: 50 V
• Self consumption: ≤ 8.4 mA / 12 V; ≤ 7.8 mA / 24 V
• Charging circuit voltage drop: ≤ 0.28 V
• Voltage drop on the load circuit: ≤ 0.20 V
• Temperature compensation coefficient: -3 mV / ℃ / 2 V (default)
• Ambient temperature: -35 ℃ ～50 ℃
• Relative humidity: ≤ 95% (N.C.)
• Protection class: IP30
• Common positive ground
• Dimensions: 200.6 x 101.3 x 57 mm
• Mounting dimension: 190 x 70 mm
• Mounting hole: 4.3
• 10 mm2 connector
• Weight: 0.5 kg
