Dobot MG400 - a robotic arm

Brand: Dobot
Product Code: AN-18777
Availability: Temporarily Out Of Stock
2,899.00€
Ex Tax: 2,395.87€
The Dobot MG400 is a lightweight, compact robotic arm that is no larger than an A4 sheet of paper. Designed to be flexible to implement in any project, easy and safe to use. The maximum payload of the robot is 750 g and the range of its arm is 440 mm. It can follow a designated motion sequence and a collision detection function. The MG400 is equipped with servo motors with a precise absolute encoder, thanks to which the robot's repeatability is up to ± 0.05 mm. With the vibration damping algorithm in the robot controller and the accuracy of the multi-axis motion trajectory ensured, the stabilization time of the repeatability band has been accelerated by 60% and the residual vibration by 70%.

Specification:

  • Name: Dobot MG400
  • Model: DT-MG400-4R075-01
  • Number of axes: 4
  • Load capacity: 500 g (max. 750 g)
  • Max. stroke length: 440 mm
  • Repeatability: ± 0.05 mm
  • Range of motion:
    • J1: ± 160°
    • J2: from -25° to 85°
    • J3: from -25° to 105°
    • J4: from -360° to 360°
  • Max. movement speed:
    • J1: 300°/s
    • J2: 300°/s
    • J3: 300°/s
    • J4: 300°/s
  • Power supply: 100 V to 240 V AC, 50/60 Hz
  • Operating voltage: 48 V
  • Power consumption: 150 W
  • Communication mode: TCP/IP, Modbus TCP
  • Working temperature: 0 °C to 40 °C
  • Software: DobotStudio 2020, SCStudio
  • Dimensions: 190 x 190 mm
  • Weight: 8 kg
