DFRobot Gravity Infrared CO2 Sensor 4.5 ~ 5.5V DC 0 ~ 50000ppm ± (50ppm + 5%) 0 ~ 50 ℃

This is a 0~50000ppm wide range CO2 sensor with UART communication port. It supports Arduino, Raspberry Pi and other microcontrollers. In addition, we also have a 0~5000 ppm high precision infrared sensor with Gravity Analog interface, more easy to use: Gravity Analog Infrared CO2 Sensor (0~5000ppm).

Features

High sensitivity High resolution
Low power consumption
Excellent stability
Temperature compensation
Excellent linear output
High cycle life
Anti-water vapor interference
No poisoning
Need 5V power supply, even you are using a 3.3V microcontroller, like Genuino 101/ Raspberry Pi .etc.

Specification

Gas Detection: Carbon Dioxide (CO2)
Operating Voltage: 4.5 ~ 5.5V DC
Average Current: <85mA
Output Signal: UART/PWM/Analog output (the last two has not been developed)
Measuring Range: 0 ~ 50000ppm
Accuracy: ± (50ppm + 5% reading)
Preheating Time: 3min
Response Time: T90 < 30s
Operating Temperature: 0 ~ 50 ℃
Operating Humidity: 0 ~ 95% RH (no condensation)
Service Life: >5 years
Board Dimension : 21 * 27.11 mm/ 0.83 * 1.06 inches
Weight: 42g

Documents

WIKi

More documents

Shipping List

UART Infrared CO2 Sensor Probe (0-50000ppm) x1
Sensor Converter Board x1
6-Pin Sensor Cable x1
PH2.0 Gravity UART Cable x1
XH2.54 4-Pin header x1
