Coating thickness gauge GL-PRO-2-F

Brand: Blow
Product Code: 50-468
Availability: Temporarily Out Of Stock
112.10€
Ex Tax: 92.64€

Currently, the GL-PRO-2 varnish meter is available in three versions:

– GL-PRO-2-F , measurement only on steel sheets;

– GL-PRO-2-FA , measurement on steel and aluminum sheets (automatic material recognition);

– GL-PRO-2-FAZ , measurement on steel and aluminum sheets (automatic material recognition with the function of detecting zinc coating on steel sheets).

The GL-PRO-2 series meters are solutions based on modern 32-bit processors . As a result, fast and accurate measurement was obtained using a 12-bit converter.

The meters use an innovative measuring probe design that allows point measurements on ferromagnetic and non-magnetic materials (depending on the version), automatically recognize the tested material and inform about the type of material on the display. The survey is complete.

A distinctive feature of the GL-PRO-2-FAZ meters is the automatic recognition of whether the ferromagnetic sheet is covered with a zinc layer or not. This is very important when measuring on a car - it will reveal to us which body parts have been replaced with cheaper non-galvanized ones. The probe was completely developed by us.

The meter has a calibration function according to thickness standards (included in the kit).

The meters have a color, easy-to-read 1.8-inch LCD display, which displays current measurements, measurement statistics and all necessary functions. Control is carried out using a 4-button keyboard and an additional trigger, which, when pressed, illuminates the measurement area.

Features:

  • · measurement on sheets (automatic detection):
  • – steel, Fe (models GL-PRO-2-F, GL-PRO-2-FA, GL-PRO-2-FAZ);
  • – aluminum, Al (GL-PRO-2-FA, GL-PRO-2-FAZ models);
  • · automatic detection of zinc (Zn) on a steel sheet (only for the GL-PRO-2-FAZ model);
  • · automatic ground detection (not applicable to the GL-PRO-2-F model, only for steel sheets);
  • · measuring range 0-2000μm;
  • · step 1μm Fe, 5μm nFe;
  • · minimum measuring area nFe 15x15mm, Fe 5x5mm;
  • built-in probe, flexible, ending with a so-called ball;
  • · measurement statistics (number, maximum, minimum, average, previous);
  • · 3 operating modes: continuous measurement, measurement hold (HOLD 1), measurement stop (HOLD 2);
  • · possibility of manually setting the measurement mode, Fe or Al;
  • · measurement memory 960 units;
  • · measuring assistant for the automotive industry (graphic + text);
  • · calibration (using tiles and thickness standard);
  • · sound alarm;
  • · LED illuminating the measuring area;
  • power supply: two AA (R6) alkaline batteries;
