Clamp meter Habotest HT206A

Brand: Habotest
Product Code: HT206A
Availability: 4-6 business days
Planuojama gavimo data po užsakymo: 2025-02-07

23.40€
Ex Tax: 19.34€

Qty

Add to Wish List

Current measuring pliers Habotest HT206A are designed to check alternating voltage, alternating current and resistance. You can also easily check the continuity and the true value of RMS. Equipped with a 2-color backlit LCD display, you will find not only the measurement results, but also the low battery indicator. So you can use the HT206A comfortably. In addition, the backlight will turn orange when the measured voltage value exceeds 80 V and the current exceeds 3 A. The built-in flashlight provides bright lighting, which means you can work in dark places without problems. The device is also facilitated by intuitive buttons that allow you to quickly and conveniently select a function, use the MAX / MIN metering option, and turn the light on or off. An added benefit is the ability to store data.

Specification

Model HT206A
DC voltage measuring range 600 mV / 6 V / 60 V / 600 V ± (0.5% + 5)
AC voltage measuring range 6V / 60V / 600V ± (0.8% + 5)
Current measuring range DC 60 A / 600 A ± (2.5% + 5)
AC measuring range 60 A / 600 A ± (2.5% + 5)
Resistance measuring range 600 Ω / 6 kΩ / 60 kΩ / 600 kΩ / 6 MΩ / 60 MΩ ± (1.0% + 5)
Capacitance range 10 nF / 100 nF / 1 μF / 10 μF / 100 μF / 1 mF / 10 mF / 100 mF ± (4.0% + 3)
Frequency measuring range 10 Hz / 100 Hz / 1 kHz / 10 kHz / 100 kHz / 1 MHz / 10 MHz ± (1.0% + 3)
Capacitance range 10 nF / 100 nF / 1 μF / 10 μF / 100 μF / 1 mF / 10 mF / 100 mF ± (4.0% + 3)
Frequency measuring range 10 Hz / 100 Hz / 1 kHz / 10 kHz / 100 kHz / 1 MHz / 10 MHz ± (1.0% + 3)
Duty cycle measurement range: 1% to 99% ± (3.0% + 3)
Temperature measuring range -40 ° C-1000 ° C ± (1.0% + 2);
-40 ° F-1832 ° C ± (1.0% + 2)
Number of calculations 6000
Range selection is automatic
Continuity test
sound and light alarm
Capacitance range 10 nF / 100 nF / 1 μF / 10 μF / 100 μF / 1 mF / 10 mF / 100 mF ± (4.0% + 3)
Frequency measuring range 10 Hz / 100 Hz / 1 kHz / 10 kHz / 100 kHz / 1 MHz / 10 MHz ± (1.0% + 3)
Duty cycle measurement range: 1% to 99% ± (3.0% + 3)
Temperature measuring range -40 ° C-1000 ° C ± (1.0% + 2);
-40 ° F-1832 ° C ± (1.0% + 2)
Number of calculations 6000
Range selection is automatic
Continuity test
Diode testing
Data storage
Lighting
Flashlight
DCA
Low battery indicator
Automatic shutdown
Actual RMS value
LPF
MAX / MIN
LowZ
Power supply: 2x AAA 1.5 V battery (included)
Weight approximately 260 g
Dimensions 193x73x34 mm
Jaw size ~ 26x44 mm
Safety EN61010-1 -2-030; EN61010-2-033, EN61326-1 CAT III 600V

Tags: clamp, meter, habotest, ht206a, current, measuring, pliers
